Référence | Désignation | Prix Unitaire TTC | Qté | |||
---|---|---|---|---|---|---|
# 1 |
21200-02B02-000 2120002B02000 2120002B02000 |
CLOCHE D'EMBRAYAGE
|
Non disponible | |||
# 2 |
09167-20024-000 0916720024000 0916720024000 |
WASHER, LOCK
WASHER |
||||
# 3 |
21410-02B02-000 2141002B02000 2141002B02000 |
NOIX
|
Non disponible | |||
# 4 |
21441-02B00-000 2144102B00000 2144102B00000 |
DISQUE D'EMBRAYAGE
PLATE, DRIVE |
Non disponible | |||
# 5 |
21451-23000-000 2145123000000 2145123000000 |
DISQUE D'EMBRAYAGE ACIER
PLATE, DRIVEN ![]() |
||||
# 6 |
21462-02B01-000 2146202B01000 2146202B01000 |
DISQUE PRESSION
|
Non disponible | |||
# 7 |
09440-15014-000 0944015014000 0944015014000 |
SPRING
|
||||
# 7 |
09440-15027-000 0944015027000 0944015027000 |
SPRING
|
Non disponible | |||
# 8 |
09100-05002-000 0910005002000 0910005002000 |
BOULON 5X16
BOLT |
||||
# 9 |
09160-05017-000 09160-05043-0000916005017000 |
WASHER, 5.5X16X1.20
WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE |
||||
# 10 |
09140-16027-000 0914016027000 0914016027000 |
NUT 16MM
NUT |
||||
# 11 |
09169-16005-000 0916916005000 0916916005000 |
RONDELLE
WASHER |
||||
# 12 |
23165-02B00-000 23165-44B01-0002316502B00000 |
BUTEE
RACK, CLUTCH RELEASE |
||||
# 13 |
09263-10002-000 0926310002000 0926310002000 |
THRUST BEARING 10X22X2.8
BEARING |
||||
# 14 |
23261-41301-000 2326141301000 2326141301000 |
AXE EMBRAYAGE
PINION, RELEASE |
||||
# 15 |
09285-10004-000 0928510004000 0928510004000 |
SEAL, OIL, 10X17X5
OIL SEAL ![]() |
||||
# 16 |
09160-12035-000 09160-12086-0000916012035000 |
WASHER, 12.5X17X1.0
WASHER |
||||
# 17 |
23271-01B01-000 2327101B01000 2327101B01000 |
LEVIER
ARM, RELEASE |
Non disponible | |||
# 18 |
01107-06166-000 01500-0616A-0000110706166000 |
VIS
BOLT, CENTER |
