| Désignation | Référence | Qté |
|---|
| Désignation | Référence | Qté |
|---|
| Référence | Désignation | Prix Unitaire TTC | Qté | |||
|---|---|---|---|---|---|---|
| # 1 |
11302-41811-000 1130241811000 1130241811000 |
CARTER MOTEUR
CRANKCASE SET |
Non disponible | |||
| # 2 |
11319-33E50-000 1131933E50000 1131933E50000 |
PION
.PIN, CRANKCASE
|
||||
| # 3 |
09106-08139-000 0910608139000 0910608139000 |
BOLT, 8X120
.BOLT, 8X120(8X120)
|
||||
| # 4 |
09168-06023-000 0916806023000 0916806023000 |
.GASKET(5.8X13X1.2)
|
||||
| # 5 |
01547-0640B-000 015470640B000 015470640B000 |
VIS
.BOLT
|
||||
| # 6 |
09103-09012-000 0910309012000 0910309012000 |
.BOLT(9X95)
|
||||
| # 7 |
09103-08170-000 09103-08339-0000910308170000 |
BOLT
.BOLT, 8X55(8X55) |
||||
| # 8 |
07120-0865B-000 071200865B000 071200865B000 |
VIS
.BOLT
|
||||
| # 9 |
01547-0630B-000 015470630B000 015470630B000 |
VIS
.BOLT
|
||||
| # 10 |
01547-0640B-000 015470640B000 015470640B000 |
VIS
.BOLT
|
||||
| # 11 |
01547-0660B-000 015470660B000 015470660B000 |
VIS
.BOLT |
||||
| # 12 |
01547-0670B-000 015470670B000 015470670B000 |
VIS
.BOLT
|
||||
| # 13 |
01547-0680B-000 015470680B000 015470680B000 |
VIS
.BOLT(6X80)
|
||||
| # 14 |
09168-06023-000 0916806023000 0916806023000 |
.GASKET(5.8X13X1.2)
|
||||
| # 15 |
09168-08016-000 0916808016000 0916808016000 |
GASKET
.GASKET(8.2X14X1)
|
||||
| # 16 |
09493-28012-000 0949328012000 0949328012000 |
JET, OIL GALY MISSION
.JET(#140)
|
||||
| # 17 |
12228-48B00-0E0 1222848B000E0 1222848B000E0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0B0 1222848B000B0 1222848B000B0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0C0 1222848B000C0 1222848B000C0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0D0 1222848B000D0 1222848B000D0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0E0 1222848B000E0 1222848B000E0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0F0 1222848B000F0 1222848B000F0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0G0 1222848B000G0 1222848B000G0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 18 |
12228-48B00-0H0 1222848B000H0 1222848B000H0 |
DEMI-SEGMENT
.BEARING, CRANK THRUST
|
||||
| # 19 |
11390-35F00-000 1139035F00000 1139035F00000 |
GICLEUR
JET, PISTON COOLING |
||||
| # 20 |
09280-04004-000 0928004004000 0928004004000 |
O RING(D:1.2, ID:4.0)
O-RING(D:1.2, ID:4)
|
||||
| # 21 |
09106-06075-000 0910606075000 0910606075000 |
BOLT
BOLT(6X12)
|
||||
| # 22 |
09168-16002-000 0916816002000 0916816002000 |
GASKET(16X22X2)
|
||||
| # 23 |
09248-16013-000 0924816013000 0924816013000 |
BOUCHON
PLUG(16X12)
|
||||
| # 24 |
09248-10010-000 0924810010000 0924810010000 |
PLUG, OIL GALL
PLUG(10X10)
|
||||
| # 25 |
09168-10002-000 0916810002000 0916810002000 |
GASKET(10X14X3.6)
|
||||
| # 26 |
09280-08012-000 0928008012000 0928008012000 |
O RING, D:1.90, ID:7.8
O-RING(D:1.9, ID:7.8)
|
||||
| # 27 |
11370-35F00-000 1137035F00000 1137035F00000 |
COUVERCLE
COVER, BREATHER |
Non disponible | |||
| # 28 |
11484-35F00-000 1148435F00000 1148435F00000 |
JOINT
GASKET, BREATHER COVER |
||||
| # 29 |
01547-0630B-000 015470630B000 015470630B000 |
VIS
BOLT
|
||||
| # 30 |
09103-10041-A05 0910310041A05 0910310041A05 |
BOULON
BOLT(10X215)
|
||||
| # 31 |
09103-10041-A05 0910310041A05 0910310041A05 |
BOULON
BOLT(10X215)
|
||||
| # 32 |
09159-10115-000 0915910115000 0915910115000 |
ECROU
NUT(M10)
|
Suzuki GSX-R
Cylindrée: 1000 cc Année: 2006 Code modèle GSX-R1000 K6 (E19)
